Gate Measurement Guidelines
Make sure that what you are fixing to is 100mm taller than the gate height to allow for the top hinge and a gap underneath allowing opening and closing, the top hinge spigots from the top of the gate
Add a minimum 30mm to a maximum 60mm to allow for hinges and lip in the middle of the gates. Allow 100mm higher than the hinge end gate height for what you are fixing the gate to. This allows space for the top hinge to spigot off the top of the gate and for a gap at the bottom to allow the gate to open.
Gate Weight
DIMENSIONS |
Width: 3000mm |
Width: 3250mm |
Width: 3500mm |
Width: 3750mm |
Width: 4000mm |
Height: 1600mm |
66kg |
72kg |
75kg |
78kg |
80kg |
Height: 1800mm |
72kg |
77kg |
82kg |
84kg |
86kg |
Height: 2000mm |
77kg |
85kg |
92kg |
89kg |
94kg |
Height: 2200mm |
85kg |
92kg |
96kg |
98kg |
102kg |
Installation Instructions & Drawings
